Tri-Helix Solar Windmill
The technology incorporates BOTH solar and wind energy into a hybrid technology known as a Solar Windmill. This innovative product consists of solar panels mounted atop three rotating wind turbines. Together, the three turbines are known as the “Tri-Helix;” they resemble twisting DNA strands. This technology allows for the integration of solar and wind energy into a much more efficient sustainable energy system. The compact, low profile design means that the Solar Windmill has the most dense energy-generation capability of any renewable energy product on the market. The Tri-Helix wind turbines are also silent, which means they are completely safe for wildlife, and don’t disturb the neighbors!
High Power Output PV
The PERC 60 is a 60 cell solar panel featuring a sleek, all-black design coupled with outstanding power output. Its design makes it ideal for residential and commercial rooftop systems. Our modules receive multiple quality checks throughout the manufacturing process and are subject to stringent quality and reliability testing. Mission Solar Energy modules are Buy American Act and American Recovery and Reinvestment Act compliant.
HarvestHP Thermal Collectors
HarvestHP Collectors fit directly behind PV panels. At a width of less than 1/4″, HarvestHP Collectors require no additional space and help to maintain the aesthetic appeal of the property. By absorbing typically uncaptured solar energy the collectors will significantly increase the electric output while also generating thermal energy which can be used in various applications throughout the property The collectors can be retrofitted or installed at the same time as PV panels.
Stored thermal energy is used to disperse hot water throughout the space as commanded. Like natural gas applications, the HarvestHP System offers ON-DEMAND THERMAL ENERGY! You can access hot water for cooking, showering and other household applications, while the unit as a whole will have the benefit of hot water in laundry, cooking, cleaning, and even pool heating year-round!
Tubular Solar Thermal Collector
The highly reflective, weather-resistant CPC (Compound Parabolic Concentrator) mirror behind the vacuum tubes ensures maximum energy yield . The CPC mirror concentrates the sun’s rays on the glass tube and the absorber and thus functions like a “solar power plant” on the roof.
The CPC vacuum tube consists, similar to the construction of a thermos , of a double-walled glass tube with a vacuum gap.
The glass tubes are fused together at the end, so that a vacuum loss is excluded .
The inner glass tube is provided on its outer surface with a modern, highly selective coating and serves as an absorber. The highly efficient absorber allows the absorption of a high proportion of solar radiation and their conversion into heat. At the same time it reduces the emission of heat radiation.
